Composite Machine
Your Professional Composite Machine Supplier
Ruian Huawei Machinery Co., Ltd. is an enterprise dedicated to the research and production of plastic machinery. Its core products include film blowing machines, bag making machines, printing machines, bubble film casting machines, granulators, dry composite machines, slitting machines, tape machines, and other types of equipment that meet the diverse needs of plastic processing and packaging production.
Advanced Production and Quality Control
The factory operates with modern equipment and a skilled technical team, ensuring strict control from raw material selection to final assembly. This guarantees stable, efficient, and high-quality performance across all machinery lines.
Full-Range Solutions Across the Packaging Chain
The company offers equipment for film blowing, printing, bag making, lamination, slitting, and recycling. This complete product line supports the entire packaging chain and meets the needs of food, daily goods, industrial, and logistics applications.
High Precision and Stable Performance
Each machine is engineered for accuracy, efficiency, and long-term reliability. Whether producing films, bags, bubble materials, or granules, the equipment maintains consistent results and meets strict quality demands.
Strong Global Market Reach
Products sell well across China and are exported to Russia, Southeast Asia, the Middle East, Africa, North America, and South America. Reliable quality and stable performance have earned the brand strong recognition worldwide.
Parameter
|
FG-600 |
FG-800 |
FG-1000 |
|
600mm |
800mm |
1000mm |
|
2 layers |
2 layers |
2 layers |
|
10-100m/min |
10-100m/min |
10-100m/min |
|
φ600 |
φ600 |
φ600 |
|
90℃ |
90℃ |
90℃ |
|
36kw |
45kw |
48kw |
|
6500kg |
7200kg |
7900kg |
|
7600×2400×3300 |
7600×2400×3300 |
9600×2850×3300 |
Advantages of Composite Machine
Efficiency
One of the most significant advantages of automatic dry composite machines is their efficiency. These machines are designed to handle high volumes of work with minimal manual intervention, significantly reducing production time.
Durability
Automatic dry film laminators apply a protective layer that enhances the durability of the laminated products. This protective layer shields the product from physical damage, moisture, and other environmental factors that could degrade its quality.
Cost-Effectiveness
Investing in automatic dry composite machines can lead to significant cost savings in the long run. The reduction in manual labor and production time directly impacts operational costs.
Consistency and Quality
Automatic laminators ensure a high level of consistency and quality in the laminating process. Manual lamination can result in uneven application and air bubbles, which can compromise the product’s appearance and protection.
Versatility
These machines are versatile and can be used for a wide range of applications. Whether it’s for laminating printed materials, packaging products, or industrial components, automatic dry film laminators can handle various substrates and film types.
Ease of Use
Modern automatic dry film laminators are designed with user-friendly interfaces and automated settings that simplify operation. This ease of use reduces the need for extensive training and allows operators to quickly adapt to the machine’s functions.
Applications of Composite Machine
Aerospace Components Production
In aerospace, lightweight materials are critical for fuel efficiency and performance. Composite forming equipment enables the manufacturing of fuselage sections, wing components, and interior structures.
Automotive Body Panels
The automotive industry is shifting toward lightweight, energy-efficient vehicles. Composite forming equipment allows for rapid production of car body panels, bumpers, and interior parts.
Wind Turbine Blade Manufacturing
Wind energy relies heavily on large, durable blades made from composites. Forming equipment such as resin infusion systems and automated layup robots are used to produce these massive components.
Sporting Goods and Recreational Equipment
High-performance sporting gear, such as tennis rackets, bicycles, and skis, benefits from composite forming processes. Equipment manufacturers use vacuum bagging and resin transfer molding to produce lightweight, high-strength products.
Medical Devices and Prosthetics
In healthcare, custom prosthetics and surgical tools require precise shaping of biocompatible composites. Automated forming equipment ensures consistent quality and fit.
Operating Precautions for Composite Machine
1. The operator should wipe the machine before starting the machine, add lubricating oil, and carefully check the various parts of the loose, off, the gear with or without foreign body, the normal before the boot.
2. Pass the substrate through the guide roller, tension roller, upper rubber roller, guide roller and oven as required. Guide roller, tension roller, the substrate itself should be no wrinkles.
3. No special circumstances, the dry lamination machine should be slow start, stop should be slow down.
4. The substrate should adhere to the appropriate tension in the walking, tension is too small when the composite is easy to show oblique wrinkles; tension is too large, the substrate will be stretched in the process of vertical wrinkles. In particular, the tension of the two base materials should be coordinated to avoid the composite material after two different stress and deformation.
5. Tension adjustment can be adjusted separately: roll out the tension, feed tension, discharge tension, coiling tension.
6. After the operation can be adjusted after the discharge and into the compound when the adjustment of the drum around the right and left, to eliminate oblique wrinkles, due to the parallel cylinder inaccurate will also show wrinkles, it should be adjusted.
7. Glued anilox roller and its rubber roller can not be stained with grease or foreign matter, before the need to empty the car rolling network roller, so that the network roller with a layer of uniform glue, two roll surface can not have dry glue or foreign matter, Solvent wipe, must not be removed with a hard device.
8. Should always adjust the axial direction of the discharge shaft, put the base material walking and machine center prevail, when a roll of base material is finished, put on another tube material with tape to end to end, can not stop or Deceleration, continuous operation.
9. The clutch on the spindle should be stopped when it is disengaged.
10. Oven temperature and speed and glue formula, will directly affect the complex fastness, oven temperature can be faster to write faster, but should ensure that the solvent evaporates.
1. Inquiry---Provide us all clear requirements (total qty and package details).
2. Quotation---Official quotation from with all clear specifications from our professional team.
3. Marking Sample --- Confirm all quotation details and the final sample.
4. Production---Mass production.
5. Shipping---By sea or by air.
Packaging and Shipping
|
Packaging |
Equipment covered with air bubble film, packed with standard exporting wooden case. |
|
Shipping |
We can deliver by sea, air and express. |
Our Service
◆ In the sales service phase, multiple departments of the company collaborate to process orders, with dedicated personnel providing real-time feedback on equipment production and quality inspection progress. Customers can also stay informed of updates through online platforms or communication; Production strictly follows standards, and samples will be made for customer confirmation before formal mass production to ensure that the equipment meets expectations. In case of potential delivery delays, we will communicate and provide solutions as soon as possible.
◆ In the pre-sales service stage, a professional team will deeply communicate with customers' industry, production capacity, budget and other needs, and customize exclusive procurement and production layout plans based on equipment characteristics.
◆ In terms of after-sales service, after the delivery of the equipment, professional technicians provide free training on operation, maintenance, and troubleshooting skills for customer personnel.
